Feautures:
Modular design, easily assemble and disassemble for delivery;
Various optional accessories according to requirements (cable management slot, cantilever, etc.,).

Standards:
Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;PART1、DIN41494;PART7, ETSI standard.

Main material:
SPCC cold rolled steel;
Thickness: plinth: 1.5mm;Front and bottom beams：2.0mm, Pole: 1.2mm.

Loading capacity:
Static loading: 150KG

Surface finish:
Degreasing, pickling, phosphoric, powder coated.

Model No.

Capacity(U)

Width (mm)

Depth (mm)

Height (mm)

TA6618

18

600

600

954

TA6622

22

600

600

1131

TA6627

27

600

600

1355

TA6632

32

600

600

1575

TA6637

37

600

600

1798

TA6642

42

600

600

2020

TA6647

47

600

600

2243
